Atomic 22 Sport Edition

The Atomic 22 is a high-quality centre-console mono combining a sleek, modern design and a soft, comfortable and dry ride even in rough conditions. We’ve designed the Atomic 22 Sport to be the ultimate all-rounder. High performance for wakeboarding, tubing and skiing, whilst offering serious fishing capabilities for inshore or offshore anglers. You no longer need a dedicated water sports boat, this is literally one boat for everything!

Get Quote

Key Features

  • Versatile centre console 22ft deep-V monohull
  • 4 bow seats offering sunbed/casting platform (3 fixed / 1 removeable)
  • High gunwales, fast-back design, soft and dry ride
  • Single outboard: 200hp – 350hp
  • Twin outboards (25” shaft) 2 x 100Hp – 140Hp
  • Ample storage, under gunwale rod racks
  • Hard-top, T-top (Bimini) or foldable roof options
  • Walk-through boarding platform onto deck
  • 3 large underdeck fish hatches
  • Live well & deck wash system
  • 2 x 110L fuel tanks (ISO certified)
  • Rated for up to 7 persons & up to Category B (40nm)
  • SAMSA Small Vessel Build Certification Cat E – Cat B (40NM) = 7 pax and 9 pax (inland: rivers and dams)
atomic-sport22-gallery (7)
atomic-sport22-gallery (6)
atomic-sport22-gallery (5)
atomic-sport22-gallery (4)
atomic-sport22-gallery (3)
atomic-sport22-gallery (2)
atomic-sport22-gallery (17)
atomic-sport22-gallery (16)
atomic-sport22-gallery (15)
atomic-sport22-gallery (14)
atomic-sport22-gallery (13)
atomic-sport22-gallery (11)
  • 3 x large bow seats (storage inside)
  • 4th seat offers a full sunbed / casting platform (removeable)
  • Console, single seater, 2 x 9″ displays can be fitted
  • Leisure skippers seat, box type with undercut base, swivel backrest, storage below for cooler box(s) OR Fisherman’s skippers seat, cushioned backrest, fold down foot rest, 3 x tackle storage units: port, starboard, folding rear filliting platform, rod holders and can/flask holders in backrest
  • 2 x Built-In 110lt aluminium tanks (ISO Certified) underdeck, OR single 220L (larger tanks can be fitted)
  • Ski bar / trolling bar, cushioned backrest, double tube 50mm round bar
  • Live bait well, viewing window, light blue gel coat inner
  • Removeable cushion on live well (offers two additional seats)
  • Boarding platform, 3-tier telescopic ladder (starboard)
  • Additional boarding platform (port)
  • Wrap-around combing bolsters (knee rests, gunwale inner perimeter)
  • 3 x Fish hatches, large flush with deck, 1 x bow, 2 x stern (double as ice boxes as all encapsulated with foam)
  • Full steel package: 25x5mm keel strip, grab rails on gunwales, console seat grab rails, pop-up cleats on gunwales, anchor bollard, bow roller, wet deck scuppers, anchor hatch bleeders, 2 x U-bolts (trailer tier downs)
  • Under gunwale rod racks, 4 rods per side, flotex marine carpet finish
  • Walk-through swing door, offers easy walk through from boarding platform to deck (optional)
  • Dedicated battery storage compartment
  • Large splash / motor well for single and twin installations
  • Non-skid profile on deck and gunwales
  • Wrap-around rub rail
  • SAMSA Small Vessel Build Certification Cat E – Cat B (40NM) = 7 pax and 9 pax (inland: rivers and dams)
  • Versatile centre console 22ft deep-V monohull
  • 4 bow seats offering sunbed/casting platform (3 fixed / 1 removeable)
  • High gunwales, fast-back design, soft and dry ride
  • Single outboard: 200hp – 350hp
  • Twin outboards (25” shaft) 2 x 100Hp – 140Hp
  • Ample storage, under gunwale rod racks
  • Hard-top, T-top (Bimini) or foldable roof options
  • Walk-through boarding platform onto deck
  • 3 large underdeck fish hatches
  • Live well & deck wash system
  • 2 x 110L fuel tanks (ISO certified)
  • Rated for up to 7 persons & up to Category B (40nm)
  • SAMSA Small Vessel Build Certification Cat E – Cat B (40NM) = 7 pax and 9 pax (inland: rivers and dams)
  • Centre-console wet deck
  • Composite construction, closed cell polyurethane foam filled hull
  • Deck built from chopped strand matt sandwich SphereCore
  • Only Lloyds approved resins, woven matting and gel coats
  • SAMSA (South African Maritime Safety Authority) rating Category R – B (up to 40Nm) and for max 7 persons
  • Dual Coosa board bonded transom | Komacel (PVC) seat bases
  • LOA : 6.5m (21’3) BOA : 2620mm
  • Deadrise : 21.8 deg. Draft : 350mm
  • Transom width 2350mm | Freeboard: 1400mm (bow)
  • Freeboard : 870mm (mid-ship) | Freeboard : 470mm (transom)
  • Waterline to top of roof 2670mm
  • 2 x Built-In 110lt aluminium tanks (ISO Certified) underdeck
  • 1 x Large bow fish hatch and 2 x stern fish hatches
  • Live bait well, light blue gel coat inner, viewing window
  • Windshield & live well viewing window, structural polycarbonate
  • Walk-through deck, swing door – easy deck access from boarding platform
  • Dedicated battery storage compartment
  • Console can be partitioned to fit 3 x large trolling motor batteries
  • Wrap-around combing bolsters (cushioned knee rests gunwale inner perimeter)
  • Gunwale width 190mm false transom / rear seat
  • Gunwale width 200mm mid-ship | Gunwale width 750mm bow centre front
  • Gunwale to deck height 530mm at live well | 700mm at mid-ship
  • Gunwale to deck height 780mm at bow
  • Trailer Total Length : 7800mm (with outboard(s) to tip coupler)
  • Height: 3400mm (ground to top of rocket launchers on roof)
  • Height: 3600mm (ground to top of radar on roof)
  • Width : 2620mm (flared beam) widest part
  • Mudguard to mudguard (outer measure) 2430mm
  • Stainless keel strip 25mmx 5mm
  • Single outboard (30″ shaft) 200hp – 350hp
  • Twin outboards (25” shaft) 2 x 100Hp – 140hp
  • Boat weight : approx. 1150kg | Trailer weight: approx. 650kg
  • Total weight e.g. boat, trailer, 2 x 140hp (fuel excl.) approx. 2,800kg
  • Comprehensive 5 Year International Structural Warranty on Hull

Standard Trailer:

  • Our trailers are built to handle the harshest conditions of Africa’s roads and beach launching.
  • Galvanized steel construction
  • 2 x 1.6 ton axles (braked)
  • Standard or break-neck version (for beach launching) available
  • 15′ commercial grade tyres, high ground clearance (spare included)
  • Heavy-duty coupler, winch and rollers (12mm stainless pins for rollers)
  • HDPE strips on upstands for easy launching and loading to trailer
  • Elevated V-bar at rear, ensures keel locates first roller
  • Long rear guide boards port and starboard: treated wood, covered in foam and marine carpeting

Optional Extras:

  • 2.5m fold-away swing arm extension (keeps your tow vehicle out of the salt water when launching on slipways)
  • 12000 lbs 12v winch for beach launching fitted to trailer, with or without dedicated battery
  • EVA foam fitted on mudguards (prevents slipping when boarding)

Trailer Gallery

atomic-trailer-5
atomic-trailer-4
atomic-trailer-3
atomic-trailer-2
atomic-trailer-1
atomic-trailer-6

Colour Options

At Atomic we offer a highly customisable craft in terms of colour options! We offer colour variations for the hull, console, skipper’s seat, gunwales, T-Top, Hard Top and various EVA decking choices to allow you to express yourself best. Here are some of our most popular hull colours.

Item 1
Item 2
Item 3
Item 4
Item 5
Item 6
Item 6

When purchasing an ATOMIC 22, you get a high-end customized craft backed by the one of the best build and service teams in the business!
