Atomic 22 Offshore edition

The Atomic 22 is a high-quality centre-console mono combining a sleek, modern design and a soft, comfortable and dry ride even in rough conditions. We’ve designed our Atomic 22 Offshore to be the ultimate performance fishing vessel for inshore and offshore fishing (up to 40nm). The boat is also an excellent all-rounder and handles wakeboarding, tubing and skiing with ease! this is literally one boat for everything!

Get Quote

Key Features

  • Versatile centre console 22ft deep-V monohull
  • High gunwales, fast-back design, soft and dry ride
  • Single outboard: 200hp – 350hp
  • Twin outboards (25” shaft) 2 x 100Hp – 140Hp
  • Ample tackle storage plus 4 gunwale rod racks
  • Hard-top, T-top (Bimini) or folding roof options
  • Console, seating and deck layout designed for fishing
  • No bow seats OR 2 removable seats
  • 3 large underdeck fish hatches
  • Live well & deck wash system
  • 2 x 110L fuel tanks (ISO certified)
  • Rated for up to 7 persons and up to Cat B (40nm)
  • SAMSA Small Vessel Build Certification Cat E – Cat B (40NM) = 7 pax and 9 pax (inland: rivers and dams)
atomic-offshore22-gallery (34)
atomic-offshore22-gallery (36)
atomic-offshore22-gallery (37)
atomic-offshore22-gallery (35)
atomic-offshore22-gallery (32)
atomic-offshore22-gallery (30)
atomic-offshore22-gallery (31)
atomic-offshore22-gallery (28)
atomic-offshore22-gallery (26)
atomic-offshore22-gallery (7)
atomic-offshore22-gallery (4)
atomic-offshore22-gallery (3)
  • No bow seats OR 2 removable seats
  • Console seat (2 seater), 2 x 12″ displays can be fitted
  • Skippers seat, with storage below rear for large cooler box, tackle storage trays, cupholders and rod holders can be added
  • 2 x Built-In 110lt aluminium tanks (ISO Certified) underdeck, removeable OR single 220L (larger tanks can be fitted)
  • Ski bar / trolling bar, cushioned backrest, double tube 50mm round bar
  • 106L oval live bait well, viewing window, light blue gel coat inner
  • Removeable cushion on live well (offers two additional seats)
  • Boarding platform, 3-tier telescopic ladder (starboard)
  • Additional boarding platform (port)
  • Wrap-around combing bolsters (knee rests, gunwale inner perimeter)
  • 3 x Fish hatches, large flush with deck, 1 x bow, 2 x stern (double as ice boxes as all encapsulated with foam)
  • Full steel package: 25x5mm keel strip, grab rails on gunwales, console seat grab rails, pop-up cleats on gunwales, anchor bollard, bow roller, anchor hatch bleeders, 2 x u-bolts (trailer tier downs)
  • Under gunwale rod racks, 4 rods per side, Flotex marine carpet finish
  • Dedicated battery storage compartment e.g. 3 x 120Ah batteries
  • Large splash / motor well for single and twin installations
  • Non-skid profile on deck
  • Wrap-around rub rail
  • Built-in insulated cooler box
  • SAMSA Small Vessel Build Certification Cat E – Cat B (40NM) = 7 pax and 9 pax (inland: rivers and dams)
  • Versatile centre console 22ft deep-V monohull
  • High gunwales, fast-back design, soft and dry ride
  • Single outboard: 200hp – 350hp
  • Twin outboards (25” shaft) 2 x 100Hp – 140Hp
  • Ample tackle storage plus 4 gunwale rod racks
  • Hard-top, T-top (Bimini) or folding roof options
  • Console, seating and deck layout designed for fishing
  • No bow seats OR 2 removable seats
  • 3 large underdeck fish hatches
  • Live well & deck wash system
  • 2 x 110L fuel tanks (ISO certified)
  • Rated for up to 7 persons and up to Cat B (40nm)
  • SAMSA Small Vessel Build Certification Cat E – Cat B (40NM) = 7 pax and 9 pax (inland: rivers and dams)
  • Centre-console wet deck
  • Composite construction, closed cell polyurethane foam filled hull
  • Deck built from chopped strand matt sandwich SphereCore
  • Only Lloyds approved resins, woven matting and gel coats
  • SAMSA (South African Maritime Safety Authority) rating Category R – B (up to 40Nm) and for max 7 persons
  • Dual Coosa board bonded transom | Komacel (PVC) seat bases
  • LOA : 6.5m (21’3) BOA : 2620mm
  • Deadrise : 21.8 deg. Draft : 350mm
  • Transom width 2350mm | Freeboard: 1400mm (bow)
  • Freeboard : 870mm (mid-ship) | Freeboard : 470mm (transom)
  • Waterline to top of roof 2670mm
  • 2 x Built-In 110lt aluminium tanks (ISO Certified) underdeck, removeable if required
  • 1 x Large bow fish hatch and 2 x stern fish hatches
  • Oval 106lt live bait well, light blue gel coat inner, viewing window
  • Windshield & live well viewing window, structural polycarbonate
  • Wrap-around combing bolsters (cushioned knee rests gunwale inner perimeter)
  • Gunwale width 190mm false transom / rear seat
  • Gunwale width 200mm mid-ship | 750mm bow centre front
  • Gunwale to deck height 530mm at live well | 700mm at mid-ship
  • Gunwale to deck height 780mm at bow
  • Trailer Total Length : 7800mm (with outboard(s) to tip coupler)
  • Height: 3400mm (ground to top of rocket launchers on roof)
  • Height: 3600mm (ground to top of radar on roof)
  • Width : 2620mm (flared beam) widest part
  • Mudguard to mudguard (outer measure) 2430mm
  • Stainless keel strip 25mmx 5mm
  • Single outboard (30″ shaft) 200hp – 350hp
  • Twin outboards (25” shaft) 2 x 100Hp – 140Hp
  • Boat weight : approx. 1150kg | Trailer weight: approx. 650kg
  • Total weight e.g. boat, trailer, 2 x 140hp (fuel excl.) approx. 2,800kg
  • Comprehensive 5 Year International Structural Warranty on Hull

Standard Trailer:

  • Our trailers are built to handle the harshest conditions of Africa’s roads and beach launching.
  • Galvanized steel construction
  • 2 x 1.6 ton axles (braked)
  • Standard or break-neck version (for beach launching) available
  • 15′ commercial grade tyres, high ground clearance (spare included)
  • Heavy-duty coupler, winch and rollers (12mm stainless pins for rollers)
  • HDPE strips on upstands for easy launching and loading to trailer
  • Elevated V-bar at rear, ensures keel locates first roller
  • Long rear guide boards port and starboard: treated wood, covered in foam and marine carpeting

Optional Extras:

  • 2.5m fold-away swing arm extension (keeps your tow vehicle out of the salt water when launching on slipways)
  • 12000 lbs 12v winch for beach launching fitted to trailer, with or without dedicated battery
  • EVA foam fitted on mudguards (prevents slipping when boarding)

Trailer Gallery

atomic-trailer-5
atomic-trailer-4
atomic-trailer-3
atomic-trailer-2
atomic-trailer-1
atomic-trailer-6

Colour Options

At Atomic we offer a highly customisable craft in terms of colour options! We offer colour variations for the hull, console, skipper’s seat, gunwales, T-Top, Hard Top and various EVA decking choices to allow you to express yourself best. Here are some of our most popular hull colours.

Item 1
Item 2
Item 3
Item 4
Item 5
Item 6
Item 6

When purchasing an ATOMIC 22, you get a high-end customized craft backed by the one of the best build and service teams in the business!
